BTR 1750 D
BTR 1750 D
The BTR 1750 D Transporter is a professional-grade dumper with a hydraulically operated load box for effortless tipping—ideal for transporting firewood, stone, sand, and other building materials. Its 60° dumping angle makes it perfect for creating piles and mounds. Designed for all terrains, including slopes, it features a tight turning radius for superior maneuverability.
SKU:
Technical Specifications
Engine
Honda GX240 OHV
Horsepower
7.9 HP
Displacement
270 cm3
Starting
recoil start
Transmission
oil-bath gearbox
Gearbox
6-speed (4 forward + 2 reverse)
Gear speeds
1: 2.0, 2: 3.5, 3: 4.6, 4: 7.8, 1R: 2.0, 2R: 3.5
Clutch
belt, with automatic disengagement when the control lever is released
Steering radius
27.75 in
Steering
with independent control releases and brakes
Brakes
with automatic engagement when clutch is released
Power takeoff
independent 2100 rpm
Load capacity
1200 lbs
Loading surface
fixed
Dumping
hydraulic
Dump angle
60°
Crawler contact
23.75 in length - 7 in width
Weight
474 lbs
Available Models
Order Code
Model
Displacement
Power
Starting
Notes
68729139US
Honda GX240 OHV
270 cm3
7.9 HP
recoil start
-
