BTR 550 D
BTR 550 D
The BTR 550 D Transporter combines high power, easy handling, and a large load capacity. This professional-grade model is perfect for agricultural and construction applications. Its hydraulically operated tipping system maximizes operator efficiency during material handling tasks.
SKU:
Technical Specifications
Engine
Honda GX200 OHV
Horsepower
5.8 HP
Displacement
196 cm3
Starting
recoil start
Transmission
oil-bath gearbox
Gearbox
6-speed (4 forward + 2 reverse)
Gear speeds
1: 2.0, 2: 3.5, 3: 4.6, 4: 7.8, 1R: 2.0, 2R: 3.5
Clutch
belt, with automatic disengagement when the control lever is released
Steering radius
27.75 in
Steering
with independent control releases and brakes
Brakes
with automatic engagement when clutch is released
Power takeoff
independent 2100 rpm
Load capacity
1210 lbs
Loading surface
telescoping
Dumping
hydraulic
Dump angle
50°
Crawler contact
23.75 in length - 7 in width
Weight
474 lbs
Available Models
Order Code
Model
Displacement
Power
Starting
Notes
68729138US
Honda GX200 OHV
196 cm3
5.8 HP
recoil start
-
